Note: Tips not included. Requires Nitrogen Source to function.
|The N2 gas and preheating effect have achieved significant improvement in soldering work!
N2 soldering iron providing 70W high output
The hot N2 gas is effective for preheating.
Can be used in combination with your existing soldering station, the HAKKO FM-202, HAKKO FM-203,HAKKO FM-204,HAKKO FM-206,HAKKO FX-950,HAKKO FX-951, or with HAKKO FX-952.
Can be used in combination with the HAKKO FX-780 and HAKKO FX-791 to create an N2 System.
For one soldering iron
For two soldering irons
|Power consumption||70W (24V)|
|Temperature range||200 to 450°C|
|Tip to ground resistance||<2|
|Tip to ground potential||<2mV|
|Heating element||Composite heater|
|Total length||205mm(with 2.4D tip)|
|Weight||45g(with 2.4D tip and nozzle assembly C)|
* Total length and weight (w/o cord, tube)
* Do not set the temperature over 400°C.
