FX1002 Micro Induction Heating (RF) Soldering Iron (Hand Piece)

SKU: HFX1002-81


Available for order*

Micro Induction (RF) Heating Soldering Iron (Hand Piece)
No calibration or system settings required
Tips Not included

£80.30 Excl. VAT

Available for order*


Suitable for use with Induction Soldering Station FX-100

Conversion Kit includes Soldering Iron, Stand heat proof mat and sleeve options does not include Tip

An IH (High-Frequency Induction Heating) micro-soldering iron for the T35 Series of soldering tips

Especially suited for soldering microchips and other chips with narrow pin pitches under a microscope

FX-1002 and T35 series tip make it much easier to solder on microchips in very fine pitch (than FX-1001 and T31).

T35 is designed to obtain not only very fine shape but also sufficient thermal capacity to delivery stable soldering quality on damage sensitive products.

 H K Wentworth - HAKKO UK and Ireland distributor
With the FX-1001 soldering tip, there is a tendency to interfere with the pin on the right, but now using the FX-1002, work can be done without interference to the surrounding pins. Connectable Station
(Single iron)

Secures field of vision under a microscope with 3 mm soldering tip

2 temperature series, 350°C and 400°C

Unlike conventional temperature control system, IH (Induction Heating) system provides fixed temperatures.

Within T35 series, tips shapes are exactly the same over the different temperature series.

Temperature series 350°C: T35-03 Series
400°C: T35-02 Series

What is IH (High-Frequency Induction Heating)

Unlike resistance-based heating systems that control temperature by turning heater power on and off via a sensor, with an induction heating system the soldering tip itself produces heat and maintains a constant temperature, enabling a small soldering tip to handle high thermal capacity, high-density substrates.


Part No. Packing list
Handpiece - FX1002-81
Yellow Sleeve Assembly - B5179

Soldering Tip / Nozzle

T31 Series

Optional / Recommended Extras

Part Number Description
FX1001-81 Soldering Iron Hand piece Buy
FX1001-82 Soldering Iron Conversion Kit Buy
FX1002-82 Micro-Soldering Iron Conversion Kit Buy
B2300 Heat Proof Mat Buy
B5180 Green Sleeve Assembly for FX1002 Buy
FG-100B Tip Thermometer Buy
B2756 Tip Holder Buy
611-1 Solder Wire Holder Buy
599B Tip Cleaner Buy
B3474 Rubber Tip Cleaner Buy
FA-400 Desktop Fume Extractor Buy

Replacement Parts FX1002

  Part Number Description
1. FX1002-81 Handpiece Buy
2. B5179 B5180 Sleeve Assembly Yellow Sleeve Assembly Green Buy Buy

Tech Tips

Category Title
Top Tips Top Tips for Successful Soldering and De-Soldering Processes
Weight 0.096 kg
